Review Gigabyte 990FXA-UD7: Motherboard AMD 990FX Socket AM3+ Kelas Atas

By
June 27th, 2011 | Categories: Motherboard

Beberapa waktu lalu, kami menyajikan Preview dari Gigabyte 990FXA-UD7 ke hadapan Anda. Kini, saatnya kami memenuhi janji dengan menghadirkan review-nya. Bagaimana performa board kelas atas Gigabyte untuk chipset high-end dari AMD ini? Penasaran? Silakan simak review kami berikut ini.

Chipset 990FX merupakan kelas high-end terbaru dari AMD. Chipset ini direncanakan sebagai pasangan prosesor AMD yang akan datang, yaitu Bulldozer. Walau begitu, soket yang digunakan Bulldozer, socket AM3+, juga kompatibel dengan prosesor AMD yang menggunakan soket AM3. Backward compatibility ini cukup menguntungkan para pengguna yang ingin menggunakan Bulldozer di kemudian hari tetapi masih ingin menggunakan prosesor lamanya. Selain itu, AMD akhirnya kembali mengusung kemampuan konfigurasi multi graphic card untuk NVIDIA (SLI) di chipset ini. Ini tentunya berita gembira bagi pencinta AMD yang juga menggunakan graphic card NVIDIA.

Kali ini, kami hadirkan perwakilan dari Gigabyte dalam bentuk Gigabyte 990FXA-UD7. Bagaimana performa chipset baru AMD ini ketika digabungkan dengan platform high end Gigabyte? Mari kita lihat bersama.

Spesifikasi

CPU AM3+ Socket:

  1. Support for AMD AM3+ FX processors
  2. Support for AMD AM3 Phenom™ II processors / AMD Athlon™ II processors

(Please refer “CPU Support List” for more information.)
Hyper Transport Bus
  1. 5200 MT/s
Chipset
  1. North Bridge: AMD 990FX
  2. South Bridge: AMD SB950
Memory
  1. 4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory (Note 1)
  2. Dual channel memory architecture
  3. Support for DDR3 2000(O.C.)/1866/1600/1333/1066 MHz memory modules (Note 2)

(Please refer “Memory Support List” for more information.)
Audio
  1. Realtek ALC889 codec
  2. High Definition Audio
  3. 2/4/5.1/7.1-channel
  4. Support for Dolby Home Theater
  5. Support for S/PDIF Out
LAN
  1. 1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots
  1. 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2) (Note 3)
  2. 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2) (Note 4)
  3. 2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)(All PCI Express slots conform to the PCI Express 2.0 standard.)
  4. 1 x PCI slot
Multi-Graphics Technology
  1. Support for 2-Way/3-Way/4-Way AMD CrossFireX™ and NVIDIA SLI™ technology
Storage Interface South Bridge:

  1. 6 x SATA 6Gb/s connectors (SATA3_0~SATA3_5) supporting up to 6 SATA 6Gb/s devices
  2. Support for SATA RAID 0, RAID 1, RAID5, RAID 10 and JBOD

2 x Marvell 88SE9172 chips:

  1. 2 x SATA 6Gb/s connectors (GSATA3_6, GSATA3_7) supporting up to 2 SATA 6Gb/s devices
  2. 2 x eSATA 6Gb/s connectors (including 1 eSATA/USB Combo connector) on the back panel supporting up to 2 SATA 6Gb/s devices
  3. Support for RAID 0 and RAID 1
USB South Bridge:

  1. Up to 14 USB 2.0/1.1 ports (8 ports on the back panel, including 1 eSATA/USB Combo connector, 6 ports available through the internal USB headers)

2 x Etron EJ168 chips:

  1. Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
IEEE 1394 VIA VT6308 chip:

  1. Up to 2 IEEE 1394a ports (1 port on the back panel, 1 port available through the internal IEEE 1394a header)
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 8-pin ATX 12V power connector
  3. 1 x PCIe power connector
  4. 8 x SATA 6Gb/s connectors
  5. 1 x CPU fan header
  6. 2 x system fan headers
  7. 1 x power fan header
  8. 1 x front panel header
  9. 1 x front panel audio header
  10. 1 x S/PDIF Out header
  11. 3 x USB 2.0/1.1 headers
  12. 1 x USB 3.0/2.0 header
  13. 1 x IEEE 1394a header
  14. 1 x Trusted Platform Module (TPM) header
  15. 1 x clearing CMOS jumper
  16. 1 x clearing CMOS button
  17. 1 x power button
  18. 1 x reset button
Back Panel Connectors
  1. 1 x PS/2 keyboard/mouse port
  2. 1 x optical S/PDIF Out connector
  3. 1 x coaxial S/PDIF Out connector
  4. 1 x IEEE 1394a port
  5. 7 x USB 2.0/1.1 ports
  6. 2 x USB 3.0/2.0 ports
  7. 1 x eSATA/USB Combo connector
  8. 1 x eSATA 6Gb/s connector
  9. 1 x RJ-45 port
  10. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
  1. ITE IT8720 chip
H/W Monitoring
  1. System voltage detection
  2. CPU/System temperature detection
  3. CPU/System/Power fan speed detection
  4. CPU overheating warning
  5. CPU/System/Power fan fail warning
  6. CPU/System fan speed control (Note 5)
BIOS
  1. 2 x 32 Mbit flash
  2. Use of licensed AWARD BIOS
  3. Support for DualBIOS™
  4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
  1. Support for @BIOS
  2. Support for Q-Flash
  3. Support for Xpress BIOS Rescue
  4. Support for Download Center
  5. Support for Xpress Install
  6. Support for Xpress Recovery2
  7. Support for EasyTune (Note 6)
  8. Support for Easy Energy Saver
  9. Support for Smart Recovery
  10. Support for Auto Green
  11. Support for ON/OFF Charge
  12. Support for Cloud OC
  13. Support for 3TB+ Unlock
  14. Support for Q-Share
Bundle Software
  1. Norton Internet Security (OEM version)
Operating System
  1. Support for Microsoft Windows 7/ Vista/ XP
Form Factor
  1. ATX Form Factor; 30.5cm x 26.3cm

Pages: 1 2 3 4 5 6 7 8
