Preview Casing Cooler Master HAF Stacker
Cooler Master membuat sebuah inovasi yang memadukan dua buah jajaran produk casing mereka: HAF (High Air Flow) dan Stacker menjadi HAF Stacker. Casing ini merupakan sebuah produk yang merupakan perpaduan hal unik dari seri HAS dan Stacker, dimana fitur HAF yang memiliki fokus untuk memberikan airflow maksimal untuk sistem Anda dan Stacker yang memiliki fokus untuk memberikan expandability yang besar dikombinasikan ke dalam satu produk. Kami berkesempatan untuk mencoba casing dari Cooler Master yang satu ini!
Kali ini, kami kedatangan satu set lengkap HAF Stacker, HAF Stacker 935 yang disertai dengan 915R, dan HAF Stacker 915F yang datang terpisah. Mari simak preview HAF Stacker berikut ini.
Spesifikasi
HAF-935
|
Model |
HAF-935-KWN1 |
| Color | Black / Black |
| Materials | Bezel: Mesh/Polymer; Case body: Steel SGCC-t0.7 |
| Dimensions | 235 x 719 x 578 mm / 9.25 x 28.8 x 22.75 inch |
| Net Weight | 15.6 kg / 34.5 lbs |
| M/B Type | EATX, ATX, microATX, Mini-ITX (915R) |
| 5.25″ Drive Bays | 3 + 1 (915R) |
| 3.5″ Drive Bays | 9 (3 x modular cage) |
| SSD Bays | 9 (converted), 1 (MB tray) + 3 (915R) |
| I/O Panel | USB 3.0 x 2, USB x 2, Audio |
| Expansion Slots | 8 + 1 and 2 (915R) |
| Cooling Support (varies by stacking setup) | Top: 120mm x 2 |
| Front: 120mm x 2 / 92mm x 1 (included) | |
| Rear: 140mm (included) / 120mm x 1 | |
| Side: 120mm x 6, 140mm x 4 (915R) | |
| Radiators: 360mm x 2 / 280mm x 2 (Side) | |
| 140mm / 120mm x 1 (Rear) | |
| Power Supply Type | Standard ATX PS2 x 2 |
| Rear / Bottom Mounted | |
| Maximum Compatibility | VGA card length: 354mm / 13.9 inch |
| 360mm / 14.17 inch | |
| CPU cooler height: 180mm / 7 inch | |
| 80mm / 3.15 inch | |
| Warranty |
2 years |
HAF 915R
|
Model |
HAF-915R-KKN1 |
| Color | Black / Black |
| Materials | Bezel: Mesh/Polymer; Case body: Steel SGCC-t0.7 |
| Dimensions | 228 x 248 x 578mm / 8.97 x 9.76 x 22.75 in. |
| Net Weight | 5.5 kg / 12.12 lbs |
| M/B Type | Mini-ITX |
| 5.25″ Drive Bays |
1 |
| 3 (1 x modular cage) | |
| SSD Bays | 3 (converted) |
| I/O Panel | USB 3.0 x 2 (No reset button) / Audio |
| Expansion Slots |
2 |
| Cooling Support (varies by stacking setup) | Front: 92mm x 1 (included) |
| Side: 6 x 120mm or 4 x 140mm | |
| Radiators: 360mm x 2 / 280mm x 2 (Side) | |
| Power Supply Type | Standard ATX PSU |
| Rear / Top Mounted | |
| Maximum Compatibility | VGA card length: 360mm / 14.17 inch |
| CPU cooler height: 80mm / 3.15 inch | |
| Warranty |
2 years |
HAF 915F
| Model | HAF-915F-KKN1 |
| Color | Black / Black |
| Materials | Bezel: Mesh/Polymer; Case body: Steel SGCC-t0.7 |
| Dimensions | 228 x 248 x 578mm / 8.97 x 9.76 x 22.75 in. |
| Net Weight | 5.1 kg / 10.8 lbs |
| M/B Type | Mini-ITX |
| 5.25″ Drive Bays |
1 |
| 3.5″ Drive Bays |
3 |
| SSD Bays |
3 |
| I/O Panel |
USB 3.0 x 2 (No reset button) / Audio |
| Expansion Slots |
2 |
| Cooling Support (varies by stacking setup) | Rear: 120mm x 1 (included) |
| Side: 6 x 120mm or 4 x 140mm | |
| Radiators: 360mm x 2 / 280mm x 2 (Side) / 120mm (Rear) | |
| Power Supply Type | Standard ATX PSU |
| Front / Bottom Mounted | |
| Maximum Compatibility | VGA card length: 360mm / 14.17 inch |
| CPU cooler height: 170mm / 6.7 inch | |
| Warranty | 2 years |
