Video Review Motherboard Gigabyte Aorus Z270X Gaming K5

CPU

• Support for 7th and 6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/Intel® Core™ i3 processors/ Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
• L3 cache varies with CPU

Chipset

• Intel® Z270 Express Chipset

Memory

• 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
• * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
• Dual channel memory architecture
• Support for DDR4 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules

Onboard Graphics

• Integrated Graphics Processor-Intel® HD Graphics support:
  1. 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz
     * Support for DisplayPort 1.2 version.
  2. 1 x HDMI port, supporting a maximum resolution of 4096×2160@24 Hz
     * Support for HDMI 1.4 version.
• Maximum shared memory of 1 GB

Audio

• Realtek® ALC1220 codec
• TI Burr Brown® NE5532P operational amplifier
• Support for Sound Blaster X-Fi MB5
• High Definition Audio
• 2/4/5.1/7.1-channel
• Support for S/PDIF Out

LAN

• Killer™ E2500 LAN chip (10/100/1000 Mbit)

Expansion Slots

• 1 x PCI Express x16 slot, running at x16 (PCIEX16)
  * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
• 1 x PCI Express x16 slot, running at x8 (PCIEX8)
  * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
• 1 x PCI Express x16 slot, running at x4 (PCIEX4)
  * The PCIEX4 slot shares bandwidth with all of the PCI Express x1 slots. When the PCIEX1_1, PCIEX1_2 or PCIEX1_3 slot is populated, the PCIEX4 slot operates at up to x1 mode.
• 3 x PCI Express x1 slots

Storage Interface

• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2M_32G)
• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2A_32G)
• 1 x U.2 connector
• 3 x SATA Express connectors
• 6 x SATA 6Gb/s connectors
• Support for RAID 0, RAID 1, RAID 5, and RAID 10

Multi-Graphics Technology

• Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies
• Support for AMD Quad-GPU CrossFireX™ and 3-Way/2-Way AMD CrossFire™ technologies

USB

• Chipset+ASMedia® ASM2142 USB 3.1 Gen 2 Controller:
  1. 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support
  2. 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
• Chipset:
  1. 7 x USB 3.1 Gen 1 ports (3 ports on the back panel, 4 ports available through the internal USB headers)
  2. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors

• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x CPU fan header
• 1 x water cooling CPU fan header
• 2 x system fan headers
• 1 x system fan/water cooling pump header
• 1 x RGB (RGBW) LED strip extension cable header
• 3 x SATA Express connectors
• 6 x SATA 6Gb/s connectors
• 2 x M.2 Socket 3 connectors
• 1 x U.2 connector
• 1 x front panel header
• 1 x front panel audio header
• 1 x S/PDIF Out header
• 2 x USB 3.1 Gen 1 headers
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module (TPM) header
• 1 x Thunderbolt™ add-in card connector
• 1 x Clear CMOS jumper
• 1 x audio gain control switch

Back Panel Connectors

• 1 x PS/2 keyboard/mouse port
• 1 x DisplayPort
• 1 x HDMI port
• 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
• 1 x USB 3.1 Gen 2 Type-A port (red)
• 3 x USB 3.1 Gen 1 ports
• 2 x USB 2.0/1.1 ports
• 1 x RJ-45 port
• 1 x optical S/PDIF Out connector
• 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)

I/O Controller

• iTE® I/O Controller Chip

H/W Monitoring

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control

BIOS

• 2 x 64 Mbit flash
  Use of licensed AMI UEFI BIOS
  Support for DualBIOS™
  PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

• Support for APP Center
  • 3D OSD
  • @BIOS
  • AutoGreen
  • BIOS Setup
  • Color Temperature
  • Cloud Station
  • EasyTune
  • Easy RAID
  • Fast Boot
  • Game Boost
  • ON/OFF Charge
  • Platform Power Management
  • RGB Fusion
  • Smart Backup
  • Smart Keyboard
  • Smart TimeLock
  • System Information Viewer
  • USB Blocker
  • USB DAC-UP 2
  • V-Tuner
• Support for 3TB+ Unlock
• Support for Q-Flash
• Support for Xpress Install

Bundle Software

• Norton® Internet Security (OEM version)
• Intel® Optane™ Memory Ready

Operating System

• Windows® 10 64-bit (for 7th Generation Intel® Processors)
• Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)

Form Factor

• ATX Form Factor; 30.5cm x 24.4cm
